Features :
Features : wireless Wifi connection, ultra-low power consumption, remote active awakening, quick start.
Use : guests will be able to make video voice calls and take short videos. The owner will not need to open the door to know the information. No need for an indoor unit.
Wake up the way : the doorbell button awakens, PIR body detection wake up, mobile phone call.
Alarm : alarm push for 1 second.
Specifications :
Operating system : Number of users online Multiple users are online simultaneously. Dynamic DNS Bring your own dynamic domain name.
Processor : A powerful, high-performance, programmable media HiSilicon processor with built-in ARM926 @max 440MHz and high-speed video coprocessor.
Data collection : CCD 1/4 inch 720p scan CMOS sensor.
Sensor performance : Support automatic white balance, automatic gain control, automatic backlighting compensation. SNR ≥39dB. LUX 0.8Lux/F1.4(Color pattern, 0.3Lux/F1.4(Black and white pattern). Lens/visual Angle 1.7mm@F2.4/166°.
LED : Double filter automatic switching, six 850 - nm Φ 28 mil high power infrared lamp, night vision 10 meters.
IR control : IR opens night vision, Automatic detection of infrared and ICR, IR shuts the night vision function off the infrared and the ICR is fixed in daily viewing mode.
Video : Compression standard H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline. Video coding More stream:720P/24fps+VGA/30fps+QVGA/30fps+720P @1fsJPEG snap. resolution 1080*720. Video mode Mobile detection video, doorbell button trigger video, manual video.
Audio : input 1 channel built-in - 48dB microphone. output Built-in speaker (8 Ω 1 w). interphone Two - way voice - speak, bring back the echo cancellation. Compression standard/ code rate ADPCM/32kbps.
Network : Network protocol TCP/IP ,HTTP, TCP, UDP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPnP, RTSP, P2P. wireless network 802.11b/g/n. Wireless network security WPS Security encryption. wireless connection One-button WIFI configuration.
Storage : The TF card stores the maximum support for 32GB.
Power : Battery power supply two section 18650 core international general. Power consumption Standby current 200 uA working current 170mA.
Mis : work environment Working temperature: - 10 ~ 50 ℃, humidity is < 95%. installation Door wall mounting. material ABS.
Size : 144 mm x 74.5 mm x 32.3 mm
Weight 190 g (No battery)
- Weight
- 400g
